Tandematic Edge Guider allows extremely close pinning without mispins Latest sensor technology “sees” any color or configuration (stripes, patterns, etc.) without operator sensitively adjustment. Reflectors or below web targets are not required. Sensor operates in a zero dead-band mode for precise exact pinning. Servo-motor controlled ball screw (replacing rack & pinion) positions rail exactly at…
SLU – Decurler for Vertical Pin Applications Tandematic Decurler Assembly Low friction plate style decurlers remove edge curl before pinning section. Units included with separate knobs for both “degree of fabric engagement” and “downward force” adjustment. Quick release bayonet latch for quick / tool-less cleaning. Download our Brochure TU43-50E Pin Stenter TUC42R Clip stenter and…
Trimmer Assembly (1 RH & LH) Variable Speed gearmotor for trimming speeds to 100 m/min. Auto-lubricated shear cutters (for clean cut & extraordinary blade life). Tungsten Carbide trim blades for extended blade life. Lateral Positioning (150 mm range at 3 mm/sec) with AC linear actuator Suction nozzles at point of cutting with aspirators for…
Tandematic Gum System Application of gum to upper surface of fabric results in trim waste reduction (yield increases) not possible with conventional under-side designs. Gum thickness adjustable (via repeatable transfer roll) while machine is running without changing gum composition. Gum is transferred to tank by a peristaltic pump with level controlled by automatic overflow. Remote…
Tandematic engineers an innovative line of textile machinery serving the finishing of knit and woven fabric marketplace. Tandematic has had over 40 years in design, engineering and manufacturing textile machinery, and the new generation Tandematic continues to innovate to meet the ever-changing needs of the industry. For a custom solution, including fabric storage systems standalone…
