Tandematic Edge Guider allows extremely close pinning without mispins Latest sensor technology “sees” any color or configuration (stripes, patterns, etc.) without operator sensitively adjustment. Reflectors or below web targets are not required. Sensor operates in a zero dead-band mode for precise exact pinning. Servo-motor controlled ball screw (replacing rack & pinion) positions rail exactly at…
SLU – Decurler for Vertical Pin Applications Tandematic Decurler Assembly Low friction plate style decurlers remove edge curl before pinning section. Units included with separate knobs for both “degree of fabric engagement” and “downward force” adjustment. Quick release bayonet latch for quick / tool-less cleaning. Download our Brochure TU43-50E Pin Stenter TUC42R Clip stenter and…
Trimmer Assembly (1 RH & LH) Variable Speed gearmotor for trimming speeds to 100 m/min. Auto-lubricated shear cutters (for clean cut & extraordinary blade life). Tungsten Carbide trim blades for extended blade life. Lateral Positioning (150 mm range at 3 mm/sec) with AC linear actuator Suction nozzles at point of cutting with aspirators for…
